HLG-320H-C2100AB
HLG-320H-C2100AB MEANWELL AC-DC Single output LED driver Constant current (CC) with built-in PFC, Output 152..
$0.00USD
3992개 재고
주요 사양
이름:HLG-320H-C2100AB
상태:New
체재:Box
시리즈:HLG-320H-C-AB
공급업체 정보
MEANWELL
제품: 6448
보통 2-3 영업일 내에 발송됩니다
품질 보장
빠른 배송
기술 지원
기술 사양
| 매개변수 | 가치 |
|---|---|
| 이름 | HLG-320H-C2100AB |
| 상태 | New |
| 체재 | Box |
| 시리즈 | HLG-320H-C-AB |
| 밝기 조절 | 0-10V, 1-10V, Resistance 0-100K, PWM Signal 10V |
| 승인 | CCC, CE, EAC, ENEC, MM, UL |
| 전력(와트) | 319,20 |
| 서브포르마토 | IP65 |
| 너비(mm) | 90.00 |
| 높이(mm) | 4.38 |
| AC 입력 최대 | 305,00 |
| AC 입력 최소 | 90,00 |
| 응용 프로그램 | Lighting |
| 제조업체 | MEAN WELL |
| 제품 유형 | LED Driver |
| 격리(V) | 3.750,00 |
| 최대 출력(와트) | 319.2 |
| 입력 커넥터 | Cable |
| 입력 주파수 | 50 Hz, 60 Hz |
| 긴/배경 | 252.00 |
| 상세 설명 | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in metal boxIP65.Input range90-305Vca47-63Hz.Output in constant current2,1 A.Adjustable by external potentiometer (1,05-2,1 A).Range of output voltage with current mode constant76 to 152Vccaccording to demand load.Power:319,2 W.Efficiency typical:94%.Potentiometer:This model incorporates 1 external potentiometer that allows us to regulate the maximum output current.Regulation0% to 100% of the output intensity with a slider0-10V / 1-10V,a PWM signal of 10V with a frequency of 100Hz to 3KHz or resistance of 0 to 100K Ohms. With the regulation we can turn off the output, but we need a regulator 0-10V. Regulators 1-10V not arrive to give 0V do not shut down the output.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Length x Width x Height):252 x 90 x 43.8 mm7 years of warranty.Manufacturer: MEAN WELLThis source can work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. In this version AB, the output current can be adjusted byexternal potentiometerlocated in the housing of the source,in addition to having regulation 0-10V/1-10V, 10V PWM, or resistance.The series HLG are LED drivers, class I grounded.With metal housing IP65. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting.Can be adjusted by regulatory assets or liabilities0-10Vor1-10V, signal 10V PWM of 100Hz to 3KHz or by resistance of 0 to 100KOhmios. Does not work with dimmers Triac dimmer cutting phase.(Not to be confused with regulators TRIACs, cutting phase. This driver cannot be regular with a Triac).With potentiometers assets that you can give 0V to shut down the output without the need of a switch. Dimmers 1-10V we can only reach 10% of regulation without shutting down the output. If you want to regulate the LED strips we recommend the series PWM.Compatible with any regulator 0-10V or 1-10V-market both assets and liabilities. Some compatible models tested are:MEAN WELL DAP-04S01 (compatible with any push button normally open).SIMON: 75317BJC: 5TC8 425LEGRAND: 0784 04ABB- "NIESSEN": N2260.9SIEMENS: 5TC8424EFAPEL: Model 21210LED BOX: Model LD1160188OSRAM: Model DIM MCUJUNG: Model 240-10We can put about 20 sources for each regulator. The maximum distance is 100 meters between the regulator and the driver. |
| 출력 커넥터 | Cable |
| 입력 유형 CA | Single-phase |
| 보증 기간(년) | 7,00 |
| 원산지 | China |
| 출력 전류 mA | 1050, 1100, 1150, 1200, 1250, 1300, 1350, 1400, 1450, 1500, 1550, 1600, 1650, 1700, 1750, 1800, 1850, 1900, 1950, 2000, 2050, 2100 |
| 최소 출력 강도(mA) | 1.050,00 |
| 최대 출력 강도(mA) | 2.100,00 |
제품 설명
More details
주요 기능
- 산업 등급 품질
- RoHS 준수
- CE 인증
- 1년 보증
기술 세부 정보
LED driver dimmable.
