재고 있음 인기 제품
LDD-1400H-WDA
LDD-1400H-WDA MEANWELL DC-DC Step down LED driver Constant Current (CC), Input 6-40VDC, Output 1.4A / 3-36VD..
$0.00USD
3274개 재고
주요 사양
이름:LDD-1400H-WDA
상태:New
체재:Box
시리즈:LDD-H-WDA
공급업체 정보
MEANWELL
제품: 6448
보통 2-3 영업일 내에 발송됩니다
품질 보장
빠른 배송
기술 지원
기술 사양
| 매개변수 | 가치 |
|---|---|
| 이름 | LDD-1400H-WDA |
| 상태 | New |
| 체재 | Box |
| 시리즈 | LDD-H-WDA |
| 밝기 조절 | Analog, DALI, PWM Signal 10V |
| 승인 | EC |
| 전력(와트) | 50,40 |
| 서브포르마토 | Encapsulated |
| 너비(mm) | 23.50 |
| 높이(mm) | 10.10 |
| 응용 프로그램 | Lighting, Solar |
| 제조업체 | MEAN WELL |
| 제품 유형 | LED Driver |
| 최대 출력(와트) | 50.4 |
| 범위 DC 입력 | 6, 6,5, 7, 8, 8,1, 8,3, 8,4, 9, 9,2, 9,9, 10, 10,5, 10,8, 12, 13,2, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18, 19, 20,4, 21, 21,6, 22,5, 24, 25,2, 26,4, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36, 36,4, 38,4, 40 |
| 입력 커넥터 | Cable |
| 긴/배경 | 40.60 |
| 상세 설명 | LED driver input and continuous output in a steady stream.Specially designed for applications of solar street lights powered from battery.Format in box with connection cables.IP65.Input rangeSix-40Vcc.Output in constant current1400mA.Range of output voltage with current mode constantThreeto 36Vccaccording to demand load.The output voltage must be at least 3V lower than the input voltage. Regulator Buck (Vout < Vin).Power:50,4 W.Efficiency typical:95%.Regulation DALI0% to 100% of the output intensity. Certificate to DALI.Regulation0% to 100% of the output intensity with a PWM signal or analog from 0.1 to 5V. (Optional).Consumption without load 1mA in power-off mode.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Length x Width x Height):Age, 40.6 x 23.5 x 10,1 mm.3 years of warranty.Manufacturer: MEAN WELL.The series LDD-H-WDA are current regulators designed to feed the leds from a battery or dc voltage. These teams have regulation DALI, compatible with any system DALI. Also can be regular (optional) using a PWM signal or analog signal.This series are voltage reducers (designed for buck or step-down) that reduce the input voltage to an output voltage lower while keeping the output current constant. It is very important to consider that the supply voltage of the leds must be at least 3V lower than the supply voltage. |
| 출력 커넥터 | Cable |
| 보증 기간(년) | 3,00 |
| 원산지 | Taiwan |
| 출력 전류 mA | One thousand four hundred |
제품 설명
More details
주요 기능
- 산업 등급 품질
- RoHS 준수
- CE 인증
- 1년 보증
기술 세부 정보
LED driver input and continuous output in a steady stream.
